Carbon Nanotubes Doped with 32 wt% Graphene Nanopowder/Nanoparticles
Graphene Purity: 99%, Thickness: 5 nm, CNT Purity: >97 wt%
Carbon Nano Tubes doped with graphene, one of the promising graphene derivatives, is a hybrid structure composes of a covalently bonded graphene and carbon nano tubes.
The hybrid material, CNT doped with graphene, extends the excellent properties of low-dimensional carbon materials (e.g., graphene, carbon nanotube – CNT) such as electrical condctivity and large specific surface area. CNT doped with graphene can be used in many various applications in areas such as energy storage, supercapacitor and building blocks composite. Nanografi supplies Carbon Nanotubes Doped wtih 32 wt% Graphene products with high quantity and low price and many types for different applications.
Technical Properties:
| 32 wt% Graphene Nanopowder | ||
| Purity | 99% | |
| Thickness (nm) | 5 | |
| Diameter (μm) | 1.0-12.0 | |
| Specific Surface Area (m2/g) | 500-1200 | |
| conductivity (s/m) | 1000-1500 | |
| Shape | two-dimensional | |
| Elemental Analysis | C | O |
| 99.6 | 0.4 | |
| Carbon Nanotubes (Multi Walled Carbon Nanotubes) | ||
| Purity | > 97 wt% | |
| Color | black | |
| Average Outside Diameter (nm) | > 50 | |
| Average Inside Diameter (nm) | 5 | |
| Length (µm) | 15-25 | |
| Tap Density (g/cm3) | 0.15 | |
| True Density (g/cm3) | ~2.4 | |
| Specific Surface Area (m2/g) | > 65 | |
| Ash | < 1.5 wt% | |
| Electrical Conductivity (S/cm) | > 98 |
Applications:
Carbon NanoTubes doped with Graphene nanoplatelets show effective improvements in electrical and mechanical properties. Such improvements
include; hardness, tensile strength, specific strenght, and elastic modulus. These improvements result in wide usage of these materials for different applications. Some of these applications include; drug delivery, biosensors, CNT composites, catalysis, nanoprobes, hydrogen storage, lithium batteries, gas-discharge tubes, flat panel displays, supercapacitors, transistors, solar cells, photoluminescence, templates
